Video Kramer

VSM-4x4HFS

VSM-4x4HFS

4×4 Seamless Matrix Switcher/Multi−Scaler
Inputs
4 HDMI
Outputs
4 HDMI
Features
Modes − Seamless matrix, video wall, dual display (PIP/P&P) and quad display
Bezel Correction− In video wall mode
Max Output Resolution − 1080p
Built−in ProcAmp
Control −IR, RS−232, Ethernet
Size – 19” (1U)
Audio – E
VP-470

VP-470

3G HD-SDI ProScale™ Digital Scaler

Inputs:

    1 3G HD-SDI

Outputs:

    2 3G HD-SDI

Features:

Multi–Standard SDI, HD–SDI & 3G HD–SDI

Looping Input

Selectable Output Size & Aspect Ratio

Built–In ProcAmp Features

Controls — Front panel with OSD

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — E



FC-340

FC-340

3G HD-SDI Scaler/Embedder/Scan Converter
Inputs
1 3G HD-SDI
Outputs
2 3G HD-SDI
1 CV (BNC)
Features
Max. Data Rate − 3Gbps
Looping Input
Embedds/De−Embeds Audio
Control − RS−232 & Ethernet
Size – 19” (1U)
Audio – E/B/D
FC-340S

FC-340S

3G HD-SDI Scaler/Embedder/Scan Converter
Inputs
1 3G HD-SDI
2 AES-3id
Outputs
2 3G HD-SDI
1 CV (BNC)
2 AES-3id
Features
Max. Data Rate − 3Gbps
Looping Input
Embedds/De−Embeds Audio
Control − RS−232 & Ethernet
Size – Desktop
Audio – E/B/D

   VP-409

VP-409

Video to Computer Graphics ProScale™ Digital Scaler (up to WUXGA)

Inputs
1 CV
1 Y/C

Outputs
1 VGA

Features
Multi−Standard − NTSC & PAL
3D Interlacer
3D Comb filter
Size – TOOLS

VP-410

VP-410

Composite Video & Stereo Audio to HDMI Scaler

Inputs
1 CV

Outputs
1 HDMI

Features

Embeds Audio

Proc Amp

Size – TOOLS

Audio – U/E



VP-417

VP-417

Video to Computer Graphics, DVI & HDTV ProScale™ Digital Scaler (up to WUXGA/1080p)
Inputs
1 CV
1 Y/C
Outputs
1 VGA/HD
1 DVI
Features
Max. Resolution − WUXGA/1080p
Built−in ProcAmp.
Digital Noise Reduction
Controls − Front panel & on−screen menus.
Size – MegaTOOLS™
VP-419xl

VP-419xl

Video to Computer Graphics/HDTV ProScale™ Digital Scaler
Inputs
1 CV
1 Y/C
1 YUV
1 VGA
Outputs
1 VGA
Features
Computer or HDTV Output
VGA Input − Pass−Through
Multi−Standard − NTSC & PAL
Built−In Proc−Amp
3D Comb Filter
3:2 Pull Down
Control − IR Remote
Rack Kit − RK−1
Size – Desktop

VP-715

VP-715

Video to Computer Graphics Video & HD Scaler

Inputs:

1 CV

1 Y/C

1 YUV

Outputs:

1 VGA/HD

1 YUV/HD

Features:

A desktop converter for up–scaling composite video, s–Video (YC) and component video to VGA up to SXGA and HD resolutions. The scaled output is available on an HD–15 connector (VGA), as well as on 3 RCA connectors (HD).

Size — Desktop — Mount 2 units side–by–side in a 1U rack space with the optional RK–1 adapter.

 VP-472

VP-472

3G HD−SDI to HDMI ProScale™ Digital Scaler

Inputs:

    1 3G HD-SDI

Outputs:

    1 HDMI

Features:

Multi–Standard SDI, HD–SDI & 3G HD–SDI

Looping Input

Selectable Output Size & Aspect Ratio

Built–In ProcAmp Features

Controls — Front panel with OSD

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — E



 VP-481

VP-481

DVI & Audio to 3G HD-SDI ProScale™ Digital Scaler

Inputs:

    1 DVI-I

Outputs:

    2 3G HD-SDI

Features:

Max. Data Rate — 3Gbps

Max Resolution — 1080p

Stereo & S/PDIF Inputs

Built–In Proc Amp

Control — Front Panel with OSD

Dual HD–SDI Outputs

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — U/D/E



VP-716

VP-716

Video to Computer Graphics Video & HD Scaler

Inputs:

1 CV

1 Y/C

1 YUV

Outputs:

1 VGA/HD

1 YUV/HD

1 DVI

Features:

A desktop converter for up–scaling composite video, s–Video (YC) andcomponent video to VGA up to SXGA and HD resolutions with both analog and digital outputs.

Size — Desktop — Mount 2 units side–by–side in a 1U rack space with the optional RK–1 adapter

VP-424

VP-424

HDMI to HDMI ProScale™ Digital Scaler

 Inputs
1 HDMI
Outputs
1 HDMI

Features

Max Res − WUXGA/1080p

Scales Input Up/Down

Rack Adapter − RK−T2B

Size – MegaTOOLS™

VP-425

VP-425

Computer Graphics Video & HDTV to HDMI ProScale™ Digital Scaler

Inputs
1 VGA/HD
Outputs
1 HDMI

Features

Max. Resolution − WUXGA & 1080p

Size – MegaTOOLS™

Audio – U/E

VP-426

HDMI/Computer Graphics Video & HDTV ProScale™ Digital Scaler

Inputs:

1 VGA/HD

1 HDMI

Outputs:

1 VGA

1 HDMI

Features:Input Auto–Scanning

Built–In ProcAmp

Control — OSD (on screen display) & contact closure

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — U/E

VP-426H2

VP-426H2

4K60 4:4:4 HDCP 2.2 HDMI 2.0 PC Scaler

Inputs
1 HDMI 4K60 4:4:4
1 VGA/HD
2 Stereo (U)

Outputs
1 HDMI 4K60 4:4:4
1 VGA/HD
1 Stereo (U)

Features

HDMI 2.0

HDCP 2.2 & 1.4

4K@60 (4:4:4)

Size – MegaTOOLS™

Audio – U/E



VP-427H2

VP-427H2

4K60 4:4:4 HDMI HDCP 2.2 Receiver/Scaler with Ethernet, RS−232, IR, & Stereo Audio over Extended−Reach HDBaseT

Inputs:

1 HDBT

1 IR

Outputs:

1 HDMI 4K60 4:4:4

1 IR

1 Stereo (U)

Features:

HDMI 2.0

HDCP1.4 & HDCP2.2

Up to 4K@60 (4:4:4)

Ethernet Tunneling

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — U/E



VP-427

VP-427

HDBaseT to HDMI ProScale™ Receiver/Scaler

Inputs:

1 HDBT

1 IR

1 RS-232

Outputs:

1 HDMI

1 IR

1 RS-232

Features:

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — E

VP-435

VP-435

HDMI, Component & Computer Graphics Video to HDMI ProScale™ Digital Scaler

Inputs:

1 YUV/HD

1 VGA

1 HDMI

Outputs:

1 HDMI

Features:

Computer Graphics & HDTV Output Resolutions.

Control — Contact Closure Switching & IR

Embeds Audio to HDMI Output

Rack Kit — RK–1

Size — Desktop — Mount 2 units side–by–side in a 1U rack space with the optional RK–1 adapter.

Audio — U/E



VP-480



VP-480

Composite Video & Stereo Audio to 3G HD−SDI ProScale™ Digital Scaler

Inputs:

1 CV

Outputs:

2 3G HD-SDI

Features:

Max. Data Rate — 3Gbps

Max Resolution — 1080p

Built–In Proc Amp

Control — Front Panel with OSD

Dual HD–SDI Outputs

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — U/E



VP-482

VP-482

HDMI to 3G HD-SDI ProScale™ Digital Scaler

Inputs:

1 HDMI

Outputs:

2 3G HD-SDI

Features:

Max. Data Rate — 3Gbps

Max Resolution — 1080p

Built–In Proc Amp

Control — Front Panel with OSD

Dual HD–SDI Outputs

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — E

 VP-420

VP-420

Computer Graphics Video & HDTV ProScale™ Digital Scaler

Inputs:

1 VGA/HD

Outputs:

1 VGA/HD

Features:

Max Res — WUXGA/1080p

Scales Input Up/Down

Rack Adapter — RK–T2B

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — N/A

VP-427A

VP-427A

HDBaseT to HDMI & Audio ProScale™ Receiver/Scaler

Inputs
1 HDBT
1 IR
1 RS-232
Outputs
1 HDMI
1 IR
1 RS-232

Features

Max. Data Rate − 6.75Gbps

Bidirectional RS−232 Port

Infrared I/O Ports

System Range − Up to 70m (230ft)

ProcAmp Control

On−Screen Display

Size – MegaTOOLS™

Audio – U/E



VP-421

VP-421

Computer Graphics Video & HDTV ProScale™ Digital Scaler (with DVI Output)

Inputs:

1 VGA/HD

Outputs:

1 VGA/HD

1 DVI

Features:

Max Res — WUXGA/1080p

Scales Input Up/Down

Rack Adapter — RK–T2B

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — N/A



VP-423

VP-423

Computer Graphics ProScale™ Video-Wall Scaler

Inputs:

1 VGA/HD

Outputs:

1 VGA/HD

Features:

Max Res — WUXGA & 1080pRGB.

Looping Input

Video Wall Size up to 4×4

One VP–423 required For Each Video Wall Display

Built–in ProcAmp

Size — MegaTOOLS® — Mount 2 units side–by–side in a 1U rack space with the optional RK–T2B rack adapter.

Audio — N/A

VP-439

VP-439

HDMI, PC and CV to HDMI Classroom Switcher / Scaler

Inputs
1 HDMI
1 VGA/HD
1 CV
Outputs
1 HDMI/DVI

Features

Max Resolution − 1080p/WUXGA.

Auto Switching

Lip Sync Delay

Control − OSD (on−screen display), Web page, Ethernet, RS−232

Built−in ProcAmp

Size – Desktop

Audio – U/E

VP-510

VP-510

4K to 2K Down−Converter

Inputs
1 HDMI 4K
Outputs
1 HDMI 2K

Features

Max Data Rate − 10.2Gbps (3.4Gbps per graphic channel)

4K UHD support − 4096×2160p@24Hz & 3840×2160p@24/25/30Hz

HDMI Signal Bypass − For non−4K resolutions

HDMI looping Input

HDMI Support − 3D, Deep Color, x.v.Color™, Dolby® TrueHD, Dolby Digital Plus, DTS−HD® and 7.1 multi−channel audio

Size – DigiTOOLS®

Audio – E



Continue reading “Video Kramer”
